REDARC DC Battery Charger - Dual Input - Under Bonnet - 40A DC
Rugged under bonnet 12V 40A DC to DC battery charger. Lithium Compatible
The REDARC BCDC1225D under-bonnet Battery Charger is a 12V 40A DC to DC battery charger, capable of high performance in engine bay installations, potted to survive and thrive against heat, water and dust.
Featuring a Maximum Power Point Tracking (MPPT) solar regulator, the BCDC1225D Classic will charge from both solar and the alternator simultaneously. And, with built-in 'Green Power Priority' it will select solar charging first, meaning less load on the alternator.
Suitable for 12 or 24-volt vehicle systems, the unit will also work with either standard or variable/smart alternators.
The BCDC1240D also comes with patented charging profiles, including a lithium charging profile. The 'Dual' input range will continue to charge all other types of batteries including AGM, GEL, standard lead acid and calcium.
As a guide, the BCDC1240D is used for battery bank sizes over 200AH.
For smaller batteries of 75-200AH REDARC recommends the BCDC1225D.
Battery Charger Features
- Separate DC and solar charging inputs
- Maximises the performance and life of your auxiliary battery
- Simultaneous DC and solar charging with Green Power Priority
- Suits 12V/24V standard and variable voltage/smart alternators
- Suitable for AGM, GEL, standard lead acid, calcium and Lithium (LiFePO4) batteries
- Suitable for use on vehicles with conventional alternator charging systems
Solar Regulator Specifications
| Input Charge | Simultaneous Vehicle & Solar |
|---|---|
| Installation Type | In-cabin or under bonnet |
| Input Voltage range | 9-32V |
| Solar Range | 9-32V |
| Solar Switch on Voltage | 9V |
| Output Power | 600W |
| Output Current | 40A |
| No Load Current | <100mA |
| Standby Current | <8mA |
| Recommended input fuse | 60A |
| Recommended output fuse | 60A |
| MPPT solar regulator | Yes |
| Operating Temperature | -10 to +80 degrees celsius |
| Length | 165mm |
| Width | 120mm |
| Height | 37mm |
| Weight | 1 kg |
| Warranty | 2 Years |
